Auto Car Seat Rotating before after mechanism seat swivel 360 degree universal seat rotary swivel plate base with slide rail

Auto Car Seat Rotating before after mechanism seat swivel 360 degree universal seat rotary swivel plate base with slide rail
Auto Car Seat Rotating before after mechanism seat swivel 360 degree universal seat rotary swivel plate base with slide rail Auto Car Seat Rotating before after mechanism seat swivel 360 degree universal seat rotary swivel plate base with slide rail Auto Car Seat Rotating before after mechanism seat swivel 360 degree universal seat rotary swivel plate base with slide rail Auto Car Seat Rotating before after mechanism seat swivel 360 degree universal seat rotary swivel plate base with slide rail

Large Image :  Auto Car Seat Rotating before after mechanism seat swivel 360 degree universal seat rotary swivel plate base with slide rail

Product Details:
Place of Origin: Shanxi, China
Brand Name: HWHongRV
Model Number: HS-SL385
Payment & Shipping Terms:
Minimum Order Quantity: 2 sets
Price: $69.00/sets 2-18 sets
Packaging Details: carton
Contact Now

Auto Car Seat Rotating before after mechanism seat swivel 360 degree universal seat rotary swivel plate base with slide rail

Description
Model: OTHER Year: OTHER
Type: General Seat Material: Steel
Car Fitment: OTHER Size: 390*360*40mm
Color: Black Product Category: Rotating Mechanism With Slider
Rotation Range: 0~360degree Adjust Angle Range: 90degree
Outer Slide Rail Length: 385mm Application: Van Campervan Caravan Motorhome
Function: Slide And Rotation Function Products: Auto Car Seat Rotating Before After Mechanism Seat Swivel 360 Degree
Keywords: Universal Seat Rotary Swivel Plate Base With Slide Rail Design Style: Luxury

Camper Van Seat Adapter with Slide Auto Car Seat Rotating before after mechanism seat swivel 360 degree universal seat rotary swivel plate base with slide rail
Specification
Product Category
Rotating Mechanism with slider
Product Code
HS-SL385
Appearance size
390*360*40mm(the height including knob is 95mm)
Rotation Range
0º~360º
Adjust gears of the rotating
4
Adjust angle range
90°
Travel of the slider
22cm
Outer Slide Rail Length
385mm
Net weight/gross weight
10kg/11kg
Carton size
400*400*100mm
Material
stainless steel, carbon steel, hot rolled steel , copper, iron, etc
Application
Great for MPV, caravan and motorhomes.

Advantage:

* The little slide make the seat can go front and after
* The rotating mechanism can change the seat orientation
* The slider and swivel has the respectively operation lever

How to install van seat rails to the swivel

It need two main parts of the car seat swivel and double lock rails. Here we come to connect the slider to the swivel.

First,we would better We'd better break the handle wider, That will make the handle clip stronger. Then put the rails with
adjustable bar in the middle on the swivel. And then connect them with screw before installation, the next We have to find the
connect holes on the rails, Please note it , The sliding shell is on top, and the Sliding core faces the turntable, and then
remove the slider shell to other end ,you will see the connecting holes, you can use an electric screwdriver, and by the same way,
you connect the swivel with other end of the slider.
Now , the turntable and slide are combined into one mechanism with multifunction .

Product Description
Auto Car Seat Rotating before after mechanism seat swivel 360 degree universal seat rotary swivel plate base with slide rail 0
Auto Car Seat Rotating before after mechanism seat swivel 360 degree universal seat rotary swivel plate base with slide rail 1
Auto Car Seat Rotating before after mechanism seat swivel 360 degree universal seat rotary swivel plate base with slide rail 2
Auto Car Seat Rotating before after mechanism seat swivel 360 degree universal seat rotary swivel plate base with slide rail 3
FAQ
Q1. What is your terms of packing?
A: Generally, we pack our goods in cartons. we can also pack it as your requirement.
Q2. What is your terms of delivery?
A: EXW,FOB or CIF according to the different conditon.
Q3. How about your delivery time?
A: Generally, it will take 1 to 50 days after receiving your payment, we always has goods in rich stock,but specific delivery time
depends on the items and the quantity of your order.
Q4. What is your terms of payment?
A: As for the big amount,T/T 50% as deposit, and 50% before delivery. We'll show you the photos of the products and packages
before you pay the balance.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings.
Q6.what is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
